Zapier automation

IN + OUT: /api/webhooks, POST /api/v1/infer

Content reviewed 2026-09-11.

Zapier document extraction automation can start with an incoming file or a finished result. Use a scoped API key to submit the document, then catch the signed extraction.completed webhook and map the reviewed fields into a spreadsheet, CRM or another Zapier action. Verify the signature before the Zap writes anywhere.

Open this integration in the app or read the public API and webhook guide.

Stop exporting and importing the same rows by hand

Extraction produces a table, but the table is only useful once it lands where the team works, and that usually means several different places.
Without automation, distributing rows means exporting a file and re-importing it everywhere, by hand, every time.
Most of the people who need this are not engineers; the tooling to wire a pipeline should not assume a developer is around.
Automation is only safe when it can tell a genuine event from a spoofed one. An unsigned webhook is a fake-data risk.

How the Zapier connection works

01. Create a Zapier webhook trigger

In Zapier, choose the Webhooks app, create a Catch Hook trigger, and copy its public endpoint URL.

02. Register it as a Dynamite Docs webhook

Add that URL as a webhook endpoint in Dynamite Docs. Endpoints must be public HTTPS URLs, and payloads are signed with HMAC-SHA256.

03. Map the fields in the Zap

Zapier shows the received columns, rows, metadata, and confidence. Map them into the action app, a spreadsheet row or a CRM contact.

04. Send documents in via the API

For the IN direction, a Zapier Webhooks action POSTs a file to /api/v1/infer with a scoped key and consumes the structured response.

Zapier trigger and API calls

A Zap uses the following trigger, payload and API call:

Trigger: extraction.completed → Catch Hook
Payload: columns, rows, metadata, confidence
Signature: HMAC-SHA256 (X-Dynamite-Signature)
Send documents in: POST /api/v1/infer with a key
Destinations: apps available through Zapier actions
Retries: backoff + jitter, up to 3 attempts

Dynamite Docs invoice line-item table with descriptions, quantities and amounts — Review the extracted table before sending its rows to another application.

A realistic example

A vendor-onboarding Zap assembled in minutes:

Step	Module	What happens
Trigger	Catch Hook	Receives extraction.completed from Dynamite Docs
Check	Filter	Keeps only W-9 documents with confidence above 0.9
Create	HubSpot contact	Writes vendor name and tax ID to the CRM
Store	Google Sheets row	Appends the row to the vendor register

What to validate before relying on it

Verify the webhook signature before the Zap performs an action, then test filters and field mappings with a sample extraction.

Zapier turns one extraction into many side effects

A Zapier Catch Hook can receive the public webhook without a custom Zapier app. The event includes columns, rows, metadata, docType and average confidence. The Zap can then append a spreadsheet row or update a CRM record. Verify the HMAC-SHA256 signature over the raw body before any action runs.

The IN direction lets Zapier submit a document. A Zap that starts with an attachment or form submission can POST the document to /api/v1/infer with a scoped key. The response carries the structured table, which the Zap can route onward. Keys are revocable, and automated requests use the same per-document page caps and monthly processing allowance as interactive use.

Delivery reliability is built in at the webhook layer. Network errors, 429s, and 5xx retry with exponential backoff and jitter, up to three attempts, so a transient Zapier issue does not silently drop an extraction event. Zapier’s own retry behavior then takes over if a Zap step fails, which gives the pipeline two honest layers of retry instead of one.

The limits are the same as any webhook consumer. Events carry extracted data, not original file bytes, and the endpoint must be a public HTTPS URL. For teams already on Zapier, the setup is short: create the trigger, register the URL, map the fields, and turn the Zap on. For teams that prefer a DIY pipeline, the underlying webhooks and REST API are documented on their own pages.

What the Zapier connection does and does not

Does

Triggers Zaps with a signed extraction.completed webhook the moment an extraction finishes.
Lets Zaps POST documents into /api/v1/infer with a scoped key and consume the structured table.
Retries transient delivery failures so a Zapier outage does not silently drop an event.

Does not

Does not require Zapier-specific credentials or a private Dynamite Docs Zapier app.
Does not send original file bytes in webhook events. The payload carries extracted data.
Does not exempt automation from the same page caps and monthly allowance as interactive use.

Why Zapier needs no separate app

Zapier uses the public webhook and REST API. Nothing extra to install.

A no-code trigger puts extraction data in the hands of the teams that need it, including the ones that never open a terminal.

Signed delivery, retries and plan limits define what happens between the trigger and destination.

Questions, answered

How do I connect Zapier to Dynamite Docs?

Create a Catch Hook trigger in Zapier, copy its public URL, and register it in Dynamite Docs. Add a verification step before the Zap trusts the HMAC-SHA256-signed payload.

Can a Zap send documents into Dynamite Docs?

Yes. A Webhooks action POSTs the file to /api/v1/infer with a scoped key and reads the structured rows from the response.

Is there a native Dynamite Docs Zapier app?

No. The connection uses the public webhook and REST API that work without Zapier, so it never depends on a private app.

Does automation count against my allowance?

Automated requests respect the same per-document page caps and monthly allowance as interactive use. Automation is not a quota workaround.
